Motorized gate closer for pedestrian swing gates

Motorized gate closer for pedestrian swing gates

Item No. D00000176 - VENUS

The Venus is a plug-and-play motorized gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor's performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener.

Product specs

3 product(s) found

Motorized gate closer for pedestrian swing gates - VENUS-A

Item No. P00035917

Motorized gate closer with articulated arm for pedestrian swing gates - Various colors

Motorized gate closer for pedestrian swing gates - VENUS-S

Item No. P00035920

Motorized gate closer with sliding arm for pedestrian swing gates - Various colors

Motorized gate closer for pedestrian swing gates - VENUS-G

Item No. P00035921

Motorized gate closer with compact arm for pedestrian swing gates with 180° hinges - Various colors

Specifications
Installation movies
Downloads

Specifications

Perfion__Bullets	Fast and easy installation with Quick-Fix Motorized gate closer with integrated electronics 150 Nm torque Fits on 3 2/16" profiles Steel gear box Anodized aluminium cover 3 different arm options for installation Compact and vandal-proof design Integrated warning light Automated obstacle detection with reverse function Brushless motor: long lifespan and intensive usage Reversible motor with backdrivability for easy manual use - to be combined with a lock Conforms to UL/cUL 325 standard for automatic operators, tested by ETL Input main power supply: 110V AC to 240V AC Configuration via app Tested up to 500 000 cycles EN 16005 Compliant 3 inputs and 3 outputs (Max. 48W, 24V DC) For pedestrian gates up to 5 ft wide and 440 lbs
Specifications	Fast and easy installation with Quick-Fix Motorized gate closer with integrated electronics 150 Nm torque Fits on 3 2/16" profiles Steel gear box Anodized aluminium cover 3 different arm options for installation Compact and vandal-proof design Integrated warning light Automated obstacle detection with reverse function Brushless motor: long lifespan and intensive usage Reversible motor with backdrivability for easy manual use - to be combined with a lock Conforms to UL/cUL 325 standard for automatic operators, tested by ETL Input main power supply: 110V AC to 240V AC Configuration via app Tested up to 500 000 cycles EN 16005 Compliant 3 inputs and 3 outputs (Max. 48W, 24V DC) For pedestrian gates up to 5 ft wide and 440 lbs
Available in following RAL-colors
Features
